Jadulan#Firmware Advan E1C NXT Backup Normal Dari HP.Beberapa waktu lalu kami sudah membagikan Firmware Advan E1c Lengkap List Preloader.namun pada postingan ini kami ingin membagikan dengan varian NXT Lengkap juga dengan list Preloader untuk menghindari kesalahan ketika melakukan flashing.Firmware ini kami backup dari hp yang normal jaya yang bisa anda gunakan untuk perbaikan pada permasalahan Os seperti Mati total-Bootloop-Hang Logo Sdb.
Info Device
Device Brand : ADVAN
Device Model : ADVAN_E1C_NXT
Device CPU : MT6580
Device IntName : ADVAN_E1C_NXT
Device Version : 7.0
Device Compile : 12/19/2017 2:02:38 AM
Device Project : alps-mp-n0.mp2-V1.23.1_miki8321.tb.n_P31
Device ExtInfo : S7D
Support List Preloader
FlashID [0] CID : 150100464E58324D42 , Name : FNX2MB , Vendor : 15 , [SAMSUNG]
FlashID [1] CID : 150100464E36324D42 , Name : FN62MB , Vendor : 15 , [SAMSUNG]
FlashID [2] CID : 700100454838454538 , Name : EH8EE8 , Vendor : 70 , [KINGSTON]
Log BACKUP
1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey
Wait for phone...
Phone found! [ 26 ]
Sync...
Inital Boot Ok!
BB_CPU_PID : 6580
BB_CPU_NME : [MediaTek] MT6580_S00
BB_CPU_EXT : 0xCA00 , 0x8A00 , 0x0000
Processing BROM stage
Settings for BROM configured!
SecCfgVal : 0x00000000
BromVer : 0x00FF
BLVersion : 0x0001
PreLoader : Active [ Boot with PL ]
BootLdrSS : NORMAL with PRELOADER
Processing DA stage
DA Select done, will use MTK_AllInOne_DA_v5.1624.16.07
Sending and initialize DA ...
Running DA ver.4.2 on BBID : 0x94
NAND Flash : NOT INSTALLED
eMMC Flash : 70010045483845453801092A82FAA4D5
Initialize Memory ...
DRAM already initialized by Preloader
DAgent sent , init HW now
eMMC FlashIC initialized
[eMMC] : FLASH_VEN : 0x70 , OEM : 0100
[eMMC] : FLASH_INF : [KINGSTON] , 8EE8H
[eMMC] : FLASH_CID : 70010045483845453801092A82FAA4D5
[eMMC] : FLASH_BRT : 0x00400000 , 0x00400000 , 0x00400000
[eMMC] : FLASH_LEN : 0x00000001C8000000
[eMMC] : FLASH_UCP : 7296 MiB [eMMC 8 GiB]
DEV RID : 0x07740D4B351EDA9B685076330DE6B206
INT RAM : 0x00020000
EXT RAM : 0x40000000 [1 GiB]
BOOT TYPE : EMMC_FLASH_BOOT
SOC VERIFY : C1
Boot Ok!
Reading Flash Content now ...
xGPT : Normalize settings Ok!
Brand : ADVAN
ProdName : ADVAN_E1C_NXT
ProdModel : S7D
Device : ADVAN_E1C_NXT
AndroidVer: 7.0
MTKxCPU : MT6580
MTKxPRJ : alps-mp-n0.mp2-V1.23.1_miki8321.tb.n_P31
[Read Ok] : preloader_advan8321_7009.bin
[Read Ok] : lk.bin
[Read Ok] : boot.img
[Read Ok] : recovery.img
[Read Ok] : logo.bin
[Read Ok] : tz1.img
[Read Ok] : tz2.img
[Read Ok] : secro.img
[Read Ok] : system.img
[Read Ok] : cache.img
[Read Ok] : userdata.img
[ScatCFG] : MT6580 / V1.1.2 / advan8321_7009 / EMMC
Android Info saved
HWConfig Info saved
FW Size : 2659 MiB
Scatter saved to : C:\Users\Ketua Teknisi HP\Desktop\MT6580__ADVAN__S7D__ADVAN_E1C_NXT__7.0__alps-mp-n0.mp2-V1.23.1_miki8321.tb.n_P31\
All done!
Done!
Elapsed: 00:12:44
Reconnect Power/Cable!
Sebelum melakukan proses perbaikan,ada beberapa kebutuhan yang bisa anda siapkan
Driver Pack Android All In One
Sp Flash Tool
Firmware Advan E1C bACKUP Cm2 dONGLE
Bagi yang belum berpengalaman dalam hal flashing,bisa mengikuti langkah-langkah berikut Tutorial Cara fLASHING Semua HP androidSekian,Jadulan#Firmware Advan E1C NXT Backup Normal Dari HP.Selamat mencoba dan semoga sukses
